Machine Room Preparation
42-02-7223 C1 2-5
2
iControl DC
Ethernet and Internet Considerations
The iBox supports three Ethernet connections:
• The #3 port is for direct local connection of a laptop or desktop PC for elevator configura-
tion, program uploading, system diagnosis, or parameter adjustment using MCE iView
software. Fixed IP address: 192.168.193.001
• For multi-car, centrally dispatched installations, the #2 port provides connection between
iBoxes. The required Ethernet hub is provided by MCE and mounted in the iCentral cabi-
net. See the table below for the factory default.
• The #1 port allows the elevator controller to be connected to Local Area Network. This
allows a PC to be used to administer and monitor multiple elevator controllers using iView
software. See the table below for the factory default address for this port.
Through a net modem, ISDN, DSL or other internet access, this port may provide remote
access to the controller. Elevator parameters are protected from meddling or accidental
change because in order to write data to a controller, permission must be granted in the
machine room. If you are working from the single iView/iCue PC in the iCentral cabinet,
permission is granted automatically.
*192.168.191.101 is typically used for the iView PC.
Table 2.1 System, LAN, & 3=PC TCP/IP Addresses
Hub Group
Group IP, Primary
& Backup
Car ID Car IP
System/Serial
Hall Call Bus 1 - 4
iView PC
System all 192.168.192.201-202 1-20 192.168.192.001-020 192.168.192.211-214
LAN A 192.168.191.201-202 1-20 192.168.191.001-020 192.168.192.101-200*
LAN B 192.168.191.203-204 1-20 192.168.191.021-040
LAN C 192.168.191.205-206 1-20 192.168.191.041-060
LAN D 192.168.191.207-208 1-20 192.168.191.061-080
LAN E 192.168.191.209-210 1-20 192.168.191.081-100
Port #3 = PC (iBox ONLY), NO HUB 192.168.193.001
