Construction Mode
2-14 Manual # 42-02-7223 C1
1. Connect the cable to the encoder using the cable/connector provided.
2. Route the cable through a separate conduit to the controller cabinet.
3. Connect the controller end of the cable as shown in the job prints.
4. Verify that the encoder shield is soldered to the drain wire (wire without insulation).
Keep the cable shield connection as short as possible — connect it to the nearest shield
terminal.
The encoder used must be rated up to 15-volts.Do not coil excess Encoder cable near high voltage
components — noise may be induced. If the cable must be shortened, trim it at the controller end. Do
not cut and re-splice in the middle of the cable or shorten at the Encoder end.
