[Necessary tools and conditions for adjustment items]
* Use the AC power supply if not specied.
The USB cable (mini B type) is used for all adjustments and so it is not mentioned below.
Item
Necessary tools
Setting/remarks
CCD-EEPROM Flashram up None
TFT-EEPROM Flashram up None
Sensitivity adjustment • 5100K Color viewer Luminance LV13
• Tool lens (Fixed aperture lens)
J61185
Aperture F8 is used
• ND lter ND 3
CCD GrGb level compensation
adjustment
• 5100K Color viewer Luminance LV13
• Tool lens (Fixed aperture lens)
J61185
Aperture F8 is used
• Color bar chart Red and blue charts are used
Color sensitivity ratio adjustment • 5100K Color viewer Luminance LV13
• Tool lens (Fixed aperture lens)
J61185
Aperture F8 is used
O p e n a p e r t u r e s e n s i t i v i t y
compensation
• Brightness box (Shutter tester) Luminance LV9 Value "k" = 1.16)
• 50mmF1.4D lens
Built-in speed light adjustment • 50mmF1.4D lens Aperture F2.8 and F5.6 are used.
• Standard test paper Approx. 1.2m×1.2m
Battery check level adjustment • Constant-voltage power supply 9 [ V ] a n d 5 [ A ] o r m o r e c a n b e
supplied.
• Battery type battery tool Product without resistor
• Ammeter This must be connected between the
battery tool and camera. It can measure
approx. 1 [mA].
• Voltmeter It is used for measuring the voltage of
the constant-voltage power supply and
can measure up to 0.01 [V].
TFT display position adjustment None
CCD defect compensation • Body cap It can interrupt the light from the mount.
