Chapter 1 System Configurations and Part Names
1.4 Name of Each Part
1-59
Three-laser unit EX (C-LU3EX)
Figure 1.4-44
(1) Laser mounting position L1
(2) Laser mounting position L2
(3) Laser mounting position L3
(4) Shutter unit connector
(5) Single-mode fiber
(6) Brightness control knob
(7) Ar wavelength selector (optional)
(8) AOM connector (optional)
* For details of available lasers for each position of laser units, see Section 8.1.4, “Mountable Lasers” in
Chapter 8, “Specifications and Performance.”
(3)
(6)
(1)
(2)
(5)
(6)
(6)
(7)
(8)
(4)
To Next Page
