383Remote Flash Photography
Quick Wireless Control
Remote Repeating
1 Displayed in radio AWL when all flash units are ready.
2 Optical AWL is indicated by Y, radio AWL by Z, joint optical and radio AWL by Y and Z.
Optical AWL channel for joint optical and radio AWL is displayed only when SB-500 is used as
master flash.
3 Icons are displayed for each group when joint optical and radio AWL is used.
4 Displayed only when radio AWL or join optical and radio AWL is used.
7
3
8
21
6
5
4
1 Flash-ready indicator
1
............... 362
2 Remote flash control .................186
FP indicator.................................. 263
3 Remote flash control mode
2
.............................................. 185, 186
4 A : B ratio.............................. 368, 376
5 Flash compensation.......... 368, 376
6 Group C flash control mode
and flash level (output)
...368, 376
7 Channel
2
.............................. 185, 362
8 Link mode
4
................................... 362
7
4
8
6
231
5
1 Flash-ready indicator
1
............... 362
2 Remote flash control .................186
3 Flash level (output) ........... 370, 378
4 Remote flash control mode
2
.............................................. 185, 186
5 Number emitted (times) ...370, 378
Frequency............................ 370, 378
6 Group status
(enabled/disabled) .......... 370, 378
7 Channel
2
.............................. 185, 362
8 Link mode
4
................................... 362
