Nisca PR5350 User Manual

6
2.1.3 LCD Panel
2.1.4 LCD Operation
ITEM DESCRIPTION MODE FUNCTION
A LCD Panel Normal
User
Displays the printer’s status.
Displays the selected menu or values.
B Ready LED Green light indicates printer is ready and
will accept data.
C Error LED Indicates an error has occurred.
D Power LED Indicates the power is on.
E Ribbon Change / Menu Button Normal
User
Press this button to change the ribbon. Press
and hold this button enter User’s Mode.
Use this button for menu selections.
F Clear Button Normal
User
Used for clearing or resetting errors. It is
also used to stop continuous printing.
In some cases, it is used to set values.
G EXE Button Normal
User
Not used.
Used to execute the displayed item or to
change the setting.
A
B
C
F
G
D
E
Figure 2-3: Printer LCD panel
