Nisca PR5350 User Manual

5
E. LCD Panel
 Display’s the current status of the printer.
F. Rejected Card Exit
 Used to eject a card that encounters a problem.
G. On/Off Switch
 Turns the printer power on and off.
2.1.2 Rear of the Printer
A. Circuit Breaker
 Protection device that stops current if there is a direct short or excessive heat.
B. Interface Connection
 Available Interface Connection: Refer to Appendix A.
C. Options Connector Port
 The printer supports the attachment of an optional card lamination module.
Options connector port not available on PR53LE.
D. Power Receptacle
 Supplies power to the printer.
E. RS232C Interface
 Interface for RFID encoding and reading modules. Connect using a D-Sub 9 pin
female (DB-9) to a D-Sub 9 pin female. Cable not included. Interface is only
available on models PR5310 and PR5350.
A
B
C
D
E
Figure 2-2: Rear of printer
