G-240W-C unit data sheet
46
7368 ISAM ONT G-240W-C Product Guide
3FE-46256-AAAA-TCZZA Issue: 01
Figure 9 G-240W-C indoor ONT physical connections
Figure 10 shows the G-240W-C ONT without the fiber cover
Figure 10 G-240W-C ONT without fiber cover
Figure 11 shows the G-240W-C ONT with the fiber cover
ON/OFFPOWER
USB2USB1LAN4LAN3LAN2LAN1
TEL1 TEL2
WLAN
RESET
WPS2.4G
WPS5G
Wall
mounting
hole
Wall
mounting
hole
POTS
ports (2)
(RJ-11)
Ethernet
ports (4)
(RJ-45)
USB
ports (2)
Wi-Fi
security
buttons
2.4G and 5G
Reset
button
Power
input
Fiber optic
port
Wireless
on/off
button
On/off
button
25272
25273
ON/OFFPOWER
USB2USB1LAN4LAN3LAN2LAN1
TEL1 TEL2
WLAN
RESET
WPS2.4G
WPS5G
Fiber optic connector
(without cover)
Release 06.01.00 | March 2019 | Edition 12
