Configure a G-240W-C indoor ONT
90
7368 ISAM ONT G-240W-C Product Guide
3FE-46256-AAAA-TCZZA Issue: 01
Procedure 17 WAN networking configuration
1 Select Network > WAN from the top-level menu in the GPON Home Gateway window, as
shown in Figure 34.
Figure 34 WAN network window
Table 26 describes the fields in the WAN network window.
Table 26 WAN network parameters
Field Description
WAN Connection List Choose a WAN connection from the drop-down menu to set the
connection parameters
Connection Type Choose a connection type: IPoE or PPPoE
IP Mode Choose an IP mode from the drop-down menu: IPv4 or IPv6
Enable/Disable Select this checkbox to enable the WAN connection
NAT Select this checkbox to enable NAT
Service Select the checkboxes to enable service types for this connection
Enable VLAN Select this checkbox to enable VLAN
(1 of 2)
Release 06.01.00 | March 2019 | Edition 12
