7368 ISAM ONT G-240W-C Product Guide Configure a G-240W-C indoor ONT
Issue: 01 3FE-46256-AAAA-TCZZA 121
Procedure 35 Port forwarding configuration
1 Select Application > Port forwarding from the top-level menu in the GPON Home Gateway
window, as shown in Figure 55.
Figure 55 Port forwarding window
Table 45 describes the fields in the port forwarding window.
Table 45 Port forwarding parameters
2 Configure port forwarding.
Field Description
APPName Choose an application name from the drop-down menu
WAN Port WAN port range
LAN Port LAN port range
Internal Client Choose a connected device from the drop-down menu and enter the associated IP
address
Protocol Choose the port forwarding protocol from the drop-down menu:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this checkbox to enable mapping
WAN Connection List Choose a WAN connection from the drop-down menu
Note: only active devices are shown on this menu
Release 06.01.00 | March 2019 | Edition 12
