Nokia 7368 ISAM ONT G-240W-C - Figure 28 WLAN Ports Statistics Window

Configure a G-240W-C indoor ONT
86
7368 ISAM ONT G-240W-C Product Guide
3FE-46256-AAAA-TCZZA Issue: 01
Procedure 15 LAN networking configuration
1 Select Network > LAN from the top-level menu in the GPON Home Gateway window, as
shown in Figure 32.
Figure 32 LAN network window
Table 24 describes the fields in the LAN network window.
Table 24 LAN network parameters
Field Description
Port Mode: All Port to L2 Mode Select this checkbox to set all ports to L2 mode
Port Mode Port 1 - 4 Drop-down port mode for each port: Route mode or bridge mode
IPv4 Address IP Address of the ONT
(1 of 2)
Release 06.01.00 | March 2019 | Edition 12
