Nokia E62 Service Manual

Enhancement Type
Advanced Car Kit CK-7W
Mobile Charger DC-4
Technical specifications
Transceiver general specifications
Unit Dimensions (L x W x T) Weight (g)
Volume (cm
3
)
Transceiver with BP-5L
1500mAh li-ion battery
back
117.1 x 69.7 x 17.8 / 13.3
mm
144 (including BP-5L
battery)
103.4
Main RF characteristics for GSM850/900/1800/1900 phones
Parameter Unit
Cellular system GSM850, EGSM900 and GSM1800/1900
Rx frequency band GSM850: 869-894 MHz
EGSM900: 925 - 960 MHz
GSM1800: 1805 - 1880 MHz
GSM1900: 1930 - 1990 MHz
Tx frequency band GSM850: 824-849 MHz
EGSM900: 880 - 915 MHz
GSM1800: 1710 - 1785 MHz
GSM1900: 1850 - 1910 MHz
Output power GSM850: +5 ... + 33 dBm/3.2mW .. 2W
GSM900: +5...+31.2dBm / 3.2mW.. 1.3 W
GSM1800: +0 … +30dBm/1.0mW … 1W
GSM1900: 0...30.9dBm/1.0mW... 1.26W
Number of RF channels GSM850: 123
GSM900: 173
GSM1800: 373
GSM1900: 298
Channel spacing 200 kHz
Number of Tx power levels GSM850: 15
GSM900: 15
GSM1800: 16
GSM1900: 16
RM-88
Nokia Customer Care General Information
Page 1 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
