Nokia E62 Service Manual

Item Side Grid reference Description and value
C2004 Bottom E 4 0402C
CHIPCAP X7R
33N K 10V
0402 33n 10V
C2006 Bottom E 3 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C2025 Bottom F 4 0805C
CHIPCAP X5R
10U M 6V3
0805 10U 6V3
C2026 Bottom F 4 0805C
CHIPCAP X5R
10U M 6V3
0805 10U 6V3
C2027 Bottom F 3 0402C
Chipcap 5%
X7R 3n3 50V
C2028 Bottom F 3 0402C
Chipcap 5%
NP0 47p 50V
C2029 Bottom F 3 0402C
Chipcap 5%
X7R 3n3 50V
C2030 Bottom H 3 0402C
Chipcap 5%
X7R 270p 50V
C2031 Bottom F 3 0402C
Chipcap 5%
NP0 47p 50V
C2071 Bottom K 18
TANT_C_6.2
X3.4_H1.7
CHIPTCAP
150U M 10V
6X3.2X1.5 150u_10V 10V
C2100 Bottom G 3 0402C
CHIPCAP X7R
33N K 10V
0402 33n 10V
C2101 Bottom G 3 0402C
CHIPCAP X7R
33N K 10V
0402 33n 10V
C2102 Bottom G 3 0603C
CHIPCAP X5R
2U2 K 6V3
0603 2u2 6V3
C2103 Top F 22 0402C
Chipcap 5%
X7R 1n0 50V
C2104 Top F 22 0402C
Chipcap 5%
X7R 1n0 50V
C2200 Bottom B 9 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2201 Bottom D 9 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2202 Bottom E 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
