Item Side Grid reference Description and value
C2203 Bottom C 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2204 Bottom C 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2205 Bottom B 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2206 Bottom C 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2207 Bottom D 10 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2208 Bottom C 10 0402C
Chipcap 5%
NP0 27p 50V
C2209 Bottom C 10 0402C
Chipcap 5%
NP0 22p 50V
C2210 Bottom D 7 0603C
CHIPCAP X5R
1U K 16V 0603 1u0 16V
C2211 Bottom D 7 0603C
CHIPCAP X5R
4U7 K 6V3
0603 4u7 6.3V
C2212 Bottom C 7 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2213 Bottom D 9 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2214 Bottom D 9 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2215 Bottom E 8 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2216 Bottom E 8 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2217 Bottom D 10 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2218 Bottom C 9 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C2219 Bottom D 10 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2220 Bottom C 8 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C2221 Bottom E 7 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2222 Bottom D 7 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
