Nokia E62 Service Manual

Item Side Grid reference Description and value
C2302 Bottom B 7 0805C
CHIPCAP X5R
22U M 6V3
0805 22u 6V3
C2303 Bottom D 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2304 Bottom C 7 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C2305 Bottom E 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2306 Bottom C 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2307 Bottom C 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2309 Bottom B 5 0805C
CHIPCAP X5R
22U M 6V3
0805 22u 6V3
C2312 Bottom C 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2313 Bottom D 5 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2314 Bottom D 6 0603C
CHIPCAP X5R
4U7 K 6V3
0603 4u7 6.3V
C2315 Bottom E 7
0603C_H0.9
5
CHIPCAP X5R
1U K 25V 0603 1u0 25V
C2316 Bottom E 7 0402C
Chipcap 5%
NP0 56p 50V
C2317 Bottom D 7 0402C
Chipcap 5%
NP0 27p 50V
C2319 Bottom E 7
0603C_H0.9
5
CHIPCAP X5R
1U K 25V 0603 1u0 25V
C2700 Bottom D 16 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2800 Bottom I 11 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2801 Bottom L 10 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2802 Bottom I 10 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –11
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
