Nokia E62 Service Manual

Item Side Grid reference Description and value
C2803 Bottom I 10 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2804 Bottom I 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2805 Bottom L 9 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2807 Bottom L 10 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C2808 Bottom I 11 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2809 Bottom I 11 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2810 Bottom I 9 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2811 Bottom L 9 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2812 Bottom I 10 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2813 Bottom L 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2814 Bottom I 11 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2815 Bottom K 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2818 Bottom J 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2819 Bottom L 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C2820 Bottom I 9 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –12 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
