Nokia E62 Service Manual

Item Side Grid reference Description and value
C2830 Bottom L 11 0402C
Chipcap X7R
10% 50V 0402 1n0 50V
C3000 Bottom K 8 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3001 Bottom J 7 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C3002 Bottom J 7 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3003 Bottom J 7 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C3004 Bottom J 6 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3005 Bottom M 7 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3006 Bottom L 8 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3007 Bottom M 6 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C3008 Bottom J 7 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3009 Bottom M 7 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3010 Bottom J 12 0402C
Chipcap
+-0.25pF NP0 3p3 50V
C3011 Bottom J 6 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3017 Bottom L 8 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3018 Bottom M 6 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C3100 Bottom G 6 0402C
CHIPCAP NP0
27P J 50V 0402 27p0 50V
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –13
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
