Nokia E62 Service Manual

Item Side Grid reference Description and value
C4400 Top C 22 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C4401 Top C 22 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C4402 Top C 22 0402C
Chipcap 5%
NP0 27p 50V
C4403 Top C 22 0402C
Chipcap 5%
NP0 27p 50V
C4404 Bottom I 4 0402C
Chipcap 5%
NP0 68p 50V
C4405 Bottom I 4 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C4408 Bottom H 2 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C4409 Bottom I 2 0603C
CHIPCAP X5R
4U7 K 6V3
0603 4u7 6.3V
C4410 Bottom H 2 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C4411 Bottom I 2 0402C
Chipcap 5%
NP0 27p 50V
C4414 Bottom I 5 0603C
CHIPCAP X5R
1U K 16V 0603 1u0 16V
C4420 Bottom B 13 0402C
Chipcap X7R
5% 16V 0402 10n 16V
C4421 Bottom B 13 0402C
Chipcap X7R
5% 16V 0402 10n 16V
C4424 Bottom I 5 0402C
CHIPCAP X5R
1U K 6V3 0402 1u0 6.3V
C5200 Bottom L 12 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C5201 Bottom M 11 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C5202 Bottom L 11 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C5203 Bottom M 11 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –14 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
