Item Side Grid reference Description and value
C5204 Bottom L 11 0402C_H0.6
CHIPCAP X5R
100N M 16V
0402 100n 16V
C6031 Bottom K 3 0402C
Chipcap 5%
NP0 18p 50V
C6032 Bottom L 3 0402C
Chipcap 5%
NP0 100p 50V
C6033 Bottom L 3 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C6034 Bottom L 3 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C6035 Bottom L 4 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C6036 Bottom L 3 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C6037 Bottom L 4 0402C
CHIPCAP X5R
1U5 K 4V 0402 1u5 4V
C6038 Bottom K 4 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C6039 Bottom J 4 0402C
Chipcap 5%
NP0 18p 50V
C6041 Bottom K 3 0402C
Chipcap
+-0.25pF NP0 2p7 50V
C6042 Bottom K 4 0402C
Chipcap
+-0.25pF NP0 2p7 50V
C6050 Bottom K 3 0402C
CHIPCAP X5R
1U K 6V3 0402 1u0 6.3V
C7501 Bottom H 13 0402C
Chipcap
+-0.25pF NP0 2p7 50V
C7503 Bottom F 12 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C7504 Bottom H 13 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C7505 Bottom F 12 0402C
CHIPCAP X5R
1U K 6V3 0402 1u0 6.3V
C7506 Bottom F 12 0603C
CHIPCAP X5R
1U K 6V3 0603 1u0 6.3V
C7507 Bottom F 12 0402C
Chipcap X7R
5% 16V 0402 10n 16V
C7508 Bottom F 13 0402C
Chipcap 5%
NP0 18p 50V
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –15
Copyright © 2006 Nokia. All rights reserved.
