Nokia E62 Service Manual

Item Side Grid reference Description and value
C7509 Bottom F 12 0402C
Chipcap
+-0.25pF NP0 2p7 50V
C7510 Bottom F 13 0402C
Chipcap 5%
NP0 27p 50V
C7511 Bottom G 12 0603C
CHIPCAP NP0
2N2 G 16V
0603 2n2 16V
C7512 Bottom G 11 0402C
Chipcap
+-0.25pF NP0 2p7 50V
C7513 Bottom F 12 0402C
Chipcap X7R
10% 16V 0402 10n 16V
C7515 Bottom H 12 0402C
Chipcap
+-0.25pF NP0 3p3 50V
C7516 Bottom G 12 0402C
Chipcap 5%
X7R 470p 50V
C7517 Bottom G 12 0402C
Chipcap
+-0.25pF NP0 3p3 50V
C7518 Bottom F 13 0402C
CHIPCAP X5R
100N K 10V
0402 100n 10V
C7520 Bottom H 16 0402C
Chipcap
+-0.25pF NP0 3p3 50V
C7522 Bottom F 16 0402C
Chipcap
+-0.25pF NP0 1p8 50V
C7523 Bottom H 16 0402C
CHIPCAP X5R
1U K 6V3 0402 1u0 6.3V
C7524 Bottom F 15 0402C
CHIPCAP X5R
1U K 6V3 0402 1u0 6.3V
C7525 Bottom F 17 0402C
Chipcap 5%
NP0 18p 50V
C7530 Bottom M 4 0402C
Chipcap X7R
10% 25V 0402 4n7 25V
C7590 Bottom L 3 0402C
Chipcap X7R
5% 16V 0402 10n 16V
C7591 Top K 22 0402C
Chipcap 5%
NP0 100p 50V
C7593 Top J 22 0402C
Chipcap
+-0.25pF NP0 8p2 50V
C7594 Top J 23 0402C
Chipcap 5%
NP0 12p 50V
C7595 Top J 22 0402C
Chipcap 5%
NP0 12p 50V
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –16 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
