Nokia E62 Service Manual

Item Side Grid reference Description and value
C7596 Top K 23 0402C
Chipcap 5%
NP0 100p 50V
C7597 Bottom M 3 0402C
Chipcap 5%
NP0 100p 50V
D2200 Bottom C 8 TFBGA_108
RETU 3.02
TSA1GJWE
TFBGA108 ~ ~
D2800 Bottom K 10 uBGA_289
RAPGSM V1.1
PA uBGA289 ~ ~
D3000 Bottom L 7
FBGA133_11
.6X13.1
COMBO
256MNOR
+1GM3
+256MDDRSDR
AM FBGA133
8Mx16/16M
x16/8Mx16 ~
D4400 Bottom C 13 LLP_44
MCU E 8BIT
COP8TAB5HYQ
8 LLP44 ~ ~
F2000 Bottom C 4
0603_FUSE_
AVX2MATS
SM FUSE F 2.0A
32V 2A ~
G2200 Bottom B 12
BATTER_EEC
EP
RTC BACUP
CAPAC 311 SIZE
FOR 2.6V 4UAH 2.6V ~
G7500 Bottom H 12
VCO_DCS027
33
VCO
3296-3980MH
Z 4-BAND
MATSUSHITA
3296-3980
MHz ~
G7501 Bottom F 11
NKG3176B_
H1.0
VCTCXO
38.4MHZ 2.5V 38.4MHz ~
L2000 Bottom D 4 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2100 Top F 23
0405_2_MAT
SU
CHIP BEAD
ARRAY
2X1000R 0405
2x1000R/
100MHz ~
L2102 Bottom B 20
COIL_0603C
S
CHIP COIL 56N J
Q38/250MHZ
0603 56nH ~
L2103 Bottom B 20
COIL_0603C
S
CHIP COIL 56N J
Q38/250MHZ
0603 56nH ~
L2202 Bottom E 9 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –17
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
