Nokia E62 Service Manual

Item Side Grid reference Description and value
L2203 Bottom E 9
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L2204 Bottom E 9
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L2205 Bottom E 9 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2206 Bottom E 8
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L2270 Bottom B 8 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2271 Bottom B 8 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2272 Bottom C 8 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2273 Bottom B 8 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2301 Bottom B 5 0603_BLM
FERR.BEAD
220R/100M 2A
0R05 0603
220R/
100MHz ~
L2302 Bottom B 6
CHOKE_SER4
00_H1.2
INDUCT WW
10UH 0A65
0R35 4X4X1.2 10uH ~
L2304 Bottom D 6
CHOKE_SER3
00
CHOKE 22U M
1R5 0.35A 22uH ~
L2305 Bottom D 5
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L2306 Bottom C 5
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L4400 Top C 22
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L4401 Top C 22
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
