Item Side Grid reference Description and value
L4402 Bottom I 5
CHOKE_ELT3
KN152C
COIL 0.47MH
50MA
3.3X3.4X1.4M
M 0.47MH ~
L5200 Bottom L 12
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L6030 Bottom K 3 0402L
CHIP COIL 2N7
+-0N3
Q29/800M
0402 2n7H ~
L6031 Bottom K 4 0402L
CHIP COIL 2N7
+-0N3
Q29/800M
0402 2n7H ~
L6032 Bottom K 4 0402L
CHIP COIL 22N J
Q28/800M
0402 22nH ~
L7500 Bottom G 14 0402L
CHIP COIL 18N J
Q29/800M
0402 18nH ~
L7501 Bottom G 14 0402L
CHIP COIL 33N J
Q23/800M
0402 33nH ~
L7502 Bottom F 13
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
L7503 Bottom F 16 0402LQW
CHIP COIL 27N
C Q25/250MHZ
0402 27nH ~
L7504 Bottom G 14 0402L
CHIP COIL 47N J
Q23/800M
0402 47nH ~
L7505 Bottom G 14 0402L
CHIP COIL 22N J
Q28/800M
0402 22nH ~
L7515 Bottom H 12
0402L_H0.4
5
CHIP COIL 4N7
+-0N1
Q29/1GHZ
0402 4n7H ~
L7530 Bottom H 14 0402L
FERR.BEAD
240R7100M
0.4A 0R4 0402
240R/
100MHz ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –19
