Nokia E62 Service Manual

Item Side Grid reference Description and value
R2000 Bottom E 4 0402R
Resistor 5%
63mW 220R ~
R2001 Bottom E 4
FLIP_CHIP_8
_1.7X1.7
ASIP SINGLE
ENDED
MICROPHONE
INTERF BGA8 ~ ~
R2003 Bottom G 4 0402R
Chipres 0W06
22k F 200ppm
0402 22k ~
R2004 Bottom G 4 0402R
Chipres 0W06
22k F 200ppm
0402 22k ~
R2006 Bottom F 3 BGA11
ASIP 4 LINES
AUDIO FILTER
BGA11 ~ ~
R2007 Bottom I 3
uBGA11_1.6
X2.15
ASIP SILIC USB
OTG / ESD
BGA11 ~ ~
R2008 Bottom I 3 0404_RP
RES NETWORK
0W06 220K/
120K J 0404 220k/120k ~
R2015 Bottom D 4
BGA4_1.01X
1.07 ASIP TVS BGA4 ~ ~
R2025 Bottom F 4 0402R
Resistor 5%
63mW 10R ~
R2026 Bottom F 4 0402R
Resistor 5%
63mW 10R ~
R2030 Bottom I 3 0402R
Resistor 5%
63mW 100R ~
R2070 Bottom K 18 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
R2071 Bottom C 10 0402_NTH5
NTC RES 47K J
B=4050+-3%
0402 47k ~
R2100 Bottom G 3
FLIP_CHIP_8
_1.7X1.7
ASIP SINGLE
ENDED
MICROPHONE
INTERF BGA8 ~ ~
R2101 Bottom G 3 0402R
Resistor 5%
63mW 220R ~
R2104 Top F 23 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –21
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
