Nokia E62 Service Manual

Item Side Grid reference Description and value
R2105 Top F 23 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
R2106 Bottom C 17 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
R2107 Bottom C 17 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
R2108 Top F 22 0402R
Chipres 0W06
jumper 0402 0R ~
R2109 Top F 22 0402R
Chipres 0W06
jumper 0402 0R ~
R2200 Bottom E 10 0402R
Resistor 5%
63mW 100k ~
R2201 Bottom D 10 0402R
Resistor 5%
63mW 120k ~
R2206 Bottom B 9 0402R
Resistor 5%
63mW 1k0 ~
R2207 Bottom B 10 0402R
Resistor 5%
63mW 1k0 ~
R2208 Bottom B 10 0402R
Resistor 5%
63mW 1k0 ~
R2209 Bottom B 10 0402R
Resistor 5%
63mW 1k0 ~
R2212 Bottom B 9 0402R
Resistor 5%
63mW 470R ~
R2213 Bottom D 10 0402R
Resistor 5%
63mW 4k7 ~
R2214 Bottom E 10 0402R
Resistor 5%
63mW 4k7 ~
R2216 Bottom D 10 0402R
CHIPRES 0W06
2M2 J 0402 2M2 ~
R2307 Bottom C 5 0402R
Resistor 5%
63mW 100R ~
R2310 Bottom D 7 0402R
Resistor 5%
63mW 33R ~
R2700 Bottom D 16
uBGA8_1.47
X1.47
ASIP SIM
INTERFACE
**LOW
CAP**BGA8 ~ ~
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –22 COMPANY CONFIDENTIAL Issue 1
