Nokia E62 Service Manual

Item Side Grid reference Description and value
R3000 Bottom K 8 0402R
Resistor 5%
63mW 4k7 ~
R3002 Bottom I 10 0402R
Resistor 5%
63mW 10R ~
R3003 Bottom K 8 0402R
Resistor 5%
63mW 4k7 ~
R3004 Bottom K 8 0402R
Resistor 5%
63mW 4k7 ~
R3007 Bottom M 8 0402R
Resistor 5%
63mW 10k ~
R3008 Bottom L 8 0402R
CHIPRES 0W06
20R J 0402 20R ~
R4400 Top B 22 0402R
Resistor 5%
63mW 470k ~
R4401 Top B 22 0402R
Resistor 5%
63mW 100k ~
R4402 Top B 22 0402R
Resistor 5%
63mW 470k ~
R4403 Top A 22 0402_NTH5
NTC RES 47K J
B=4050+-3%
0402 47k ~
R4404 Bottom I 5 0402R
Chipres 0W06
jumper 0402 0R ~
R4406 Top L 22 0402_VAR
CHIP VARISTOR
VWM14V
VC50V 0402 14V/50V ~
R4407 Bottom D 13 0402R
Resistor 5%
63mW 18R ~
R4409 Bottom D 13 0402R
Resistor 5%
63mW 18R ~
R4410 Bottom D 14 0402R
Resistor 5%
63mW 1k0 ~
R4412 Top B 22 0402R
Resistor 5%
63mW 680R ~
R4413 Top C 22 0402R
Chipres 0W06
jumper 0402 0R ~
R4414 Bottom G 4 0402R
Resistor 5%
63mW 100k ~
R4423 Bottom I 2
0805R_THER
M1
CHIPRES
0W125 4R7 J
0805 4R7 ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –23
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
