Nokia E62 Service Manual

Item Side Grid reference Description and value
R4430 Bottom B 14 0402R
Resistor 5%
63mW 100k ~
R4432 Bottom D 11 0402R
Chipres 0W06
jumper 0402 0R ~
R4438 Bottom D 14 0402R
Resistor 5%
63mW 3k3 ~
R4439 Bottom D 14 0402R
Resistor 5%
63mW 3k3 ~
R4440 Bottom D 14 0402R
Resistor 5%
63mW 3k3 ~
R4441 Bottom H 3 0402R
Resistor 5%
63mW 82k ~
R4444 Bottom I 5 0402R
Chipres 0W06
5% 0402 3M3 ~
R4506 Bottom B 17 0402R
Chipres 0W06
jumper 0402 0R ~
R4507 Bottom B 17 0402R
Chipres 0W06
jumper 0402 0R ~
R4508 Bottom B 17 0402R
Chipres 0W06
jumper 0402 0R ~
R4509 Bottom B 16 0402R
Chipres 0W06
jumper 0402 0R ~
R5201 Bottom M 10 0402R
Resistor 5%
63mW 100k ~
R5202 Bottom L 10 0402R
Resistor 5%
63mW 100k ~
R5203 Bottom M 11 0402R
Resistor 5%
63mW 100k ~
R5204 Bottom L 11 0402R
Resistor 5%
63mW 2k2 ~
R6030 Bottom L 3 0402R
Resistor 5%
63mW 10k ~
R6031 Bottom K 4 0402R
Resistor 5%
63mW 10k ~
R6032 Bottom L 4 0402R
CHIPRES 0W06
2R2 J 0402 2R2 ~
R6034 Bottom K 3 0402R
Resistor 5%
63mW 10k ~
R6035 Bottom K 4 0402R
Resistor 5%
63mW 100k ~
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –24 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
