Nokia E62 Service Manual

Item Side Grid reference Description and value
R6302 Bottom H 1 0402R
Chipres 0W06
jumper 0402 0R ~
R7501 Bottom G 12 0402R
Resistor 5%
63mW 2k2 ~
R7502 Bottom H 13 0402R
CHIPRES 0W06
10K F 0402 10k ~
R7503 Bottom F 13 0402R
Resistor 5%
63mW 4k7 ~
R7504 Bottom F 12 0402R
Chipres 0W06
jumper 0402 0R ~
R7505 Bottom G 12 0402R
CHIPRES 0W06
8K2 F 0402 8k2 ~
R7506 Bottom F 13 0402R
Resistor 5%
63mW 10R ~
R7507 Bottom H 13 0402R
Resistor 5%
63mW 10R ~
R7508 Bottom F 12 0402R
Resistor 5%
63mW 10R ~
R7509 Bottom F 12 0402R
Resistor 5%
63mW 22k ~
R7510 Bottom F 17 0402R
Resistor 5%
63mW 15R ~
R7522 Bottom F 16 0402R
CHIPRES 0W06
27K F 0402 27k ~
R7523 Bottom H 16 0402R
Chipres 0W06
jumper 0402 0R ~
R7586 Bottom L 4 0402R
Resistor 5%
63mW 330R ~
R7587 Bottom M 3 0402R
Chipres 0W06
jumper 0402 0R ~
R7588 Top J 23 0402R
Chipres 0W06
jumper 0402 0R ~
R7590 Bottom M 4 0402R
Resistor 5%
63mW 1k8 ~
R7591 Top J 22 0402R
Chipres 0W06
jumper 0402 0R ~
R7592 Bottom L 4 0402R
Resistor 5%
63mW 27k ~
R7594 Bottom M 3 0402R
Resistor 5%
63mW 1k2 ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –25
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
