Nokia E62 Service Manual

Item Side Grid reference Description and value
S4401 Top L 22
BUTTON_EV
PAA
SWITCH PB
LIGHT EVPAA
15V 20MA ~ ~
T7501 Bottom G 12
TRANS_LDB1
5
TRANSF BALUN
3800
+-550MHZ
0805 ~ ~
T7520 Bottom H 17
TRANS_LDB1
5
TRANSF BALUN
1800
+-100mhz
2x1.25 ~ ~
V2302 Bottom B 5 SOD323F
SCH DI 30V 2A
SOD323F ~ ~
V4400 Top B 22
PT202MR0M
P
DI PHOTO
PT202MR0MP
620NM 1.25X2 ~ ~
V4401 Bottom I 4 SC_76
DI ZEN 100V
6% 200MW
SOD323 ~ ~
V4402 Bottom J 4 SC_76
DI ZEN 100V
6% 200MW
SOD323 ~ ~
V4403 Bottom E 14 VMT3
TR
2SC5658QRS N
50V 0A1 0W15
VMT3 ~ ~
V4404 Bottom H 4 SOT_666
TRX2+RX4
PEMD9 N&P
10K/47K 0W12
SOT666 ~ ~
V4405 Top B 22 LED_CL191
LED CL-191WB-
D-T WHITE 0`
115MCD 0603 ~ ~
V4406 Top B 22 EM3
TR PDTC114EE
N 50V
RB=RBE=10K
EM3 ~ ~
V4407 Bottom B 14 EM3
TR PDTC114EE
N 50V
RB=RBE=10K
EM3 ~ ~
V7590 Bottom M 3 SOT323
Tr NPN 12V
35mA SOT323 ~ ~
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –26 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
