Nokia E62 Service Manual

Item Side Grid reference Description and value
W6300 Bottom G 1
ANT_RENM0
5041
BT/WLAN 1.0
TP ANTENNA
RELEASE ~ ~
X2000 Bottom C 1
CON_JACK_H
R33NK_2DJA
_2S
CONN DC-JACK
2.0MM 3POL
SPR 90DEG ~ ~
X2001 Bottom K 2
USB_MITSU
MI_R415082
SMD CONN
5POL MINI-USB
B TYPE P0.8 ~ ~
X2002 Bottom E 2
JACK_T_378
840_A9
HEADSET JACK
4-POLE ~ ~
X2070 Bottom I 18
LYNX_BATT_
CONN_H7.0
SM BATTERY
CONN 3POL
SPR 12V 2A ~ ~
X2100 Bottom D 20
CONN_ANT_
DMD11562
CON PPP
ANTENNA
R1024
DMD11562 ~ ~
X2101 Bottom D 20
CONN_ANT_
DMD11562
CON PPP
ANTENNA
R1024
DMD11562 ~ ~
X2701 Bottom C 15
SIM_CONN_
M_SK_20030
0383
SM SIM CONN
2X3POL P2.54
H4.6 ~ ~
X4400 Top E 22
JST_R_JAVK_
G_1_R3
SM CONN
2X12F P0.4
30V .3A PWB/
PWB ~ ~
X4500 Bottom F 8
CONN_SD_54
742_002
SM LCD CONN
1X8 P2.0 SPR
50V 0.5A ~ ~
X4501 Bottom B 17
SMK_4309_B
_B_6P_V2
SM CONN 6P
SPR P1.3 50V
BTOB ~ ~
X5200 Bottom K 15
MINISD_SC1
S011V1S3
CONN MINISD
PUSH-PUSH
3.3V 0.5A ~ ~
X7504 Bottom M 23
SPRING_WN
9149_N10
C-SPRING
ANTENNA
active ~ ~
X7505 Bottom L 23
SPRING_WN
9149_N10
C-SPRING
ANTENNA
active ~ ~
RM-88
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –27
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
