Nokia E62 Service Manual

Item Side Grid reference Description and value
X7507 Bottom J 23
SPRING_WN
9149_N10
C-SPRING
ANTENNA
active ~ ~
Z2001 Bottom I 3
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
Z2002 Bottom H 3
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
Z2003 Bottom F 3
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
Z2004 Bottom F 3
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
Z2005 Bottom E 3
FERRITE_04
02
FERRITE BEAD
0.6R 600R/
100MHZ 0402
600R/
100MHz ~
Z4402 Top B 23
uBGA25_2.4
7X2.47
ASIP 10-CH ESD
EMI FILTER
BGA25 ~ ~
Z4403 Top C 23
uBGA25_2.4
7X2.47
ASIP 10-CH ESD
EMI FILTER
BGA25 ~ ~
Z4500 Bottom B 13
uBGA24_2.6
2X2.62
ASIP
EMIF10-1K010
F2 **PB-
FREE** ~ ~
Z4501 Bottom D 12
uBGA24_2.6
2X2.62
ASIP
EMIF10-1K010
F2 **PB-
FREE** ~ ~
Z5200 Bottom M 12
uBGA11_1.6
2X2.12
ASIP EMIF04-
MMC02F2**PB
-FREE** ~ ~
Z6030 Bottom K 4
EZFVQ42NM
61S
LTCC FILT
2441.75
+-41.75MHZ
2.5X2
2441.75MH
z ~
Z7501 Bottom G 15
FILTER_2.1X
1.7_10P_H0.
6
SAW FILT
1842.5/1960M
HZ 2.0X1.6MM
1842.5/196
0MHZ ~
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –28 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
