Item Side Grid reference Description and value
Z7503 Bottom F 15
MODULE_LM
SM43AA_34
1
TX SAW
MODULE GSM
850/900MHZ
4.5X3.2
850/900MH
z ~
Z7504 Bottom G 15
FILTER_2.1X
1.7_10P_H0.
65
DUAL RX SAW
FILTER
850/900MHZ
2016
850/900MH
z ~
Z7520 Bottom H 16
FERRITE_FB
MJ1608
FERRITE BEAD
0R01 28R/
100MHZ 0603
28R/
100MHz ~
RM-88
