About the Nokia IP390 Appliance
IP390 Security Platform Installation Guide 19
Note
Nokia recommends the use of shielded twisted-pair cables and connectors for best
Electromagnetic Interference and Immunity performance.
PMC Expansion Slots
The IP390 appliance provides two additional PMC network interface card (NIC) slots, as
described in Table 4.
Note
Nokia products only support NICs purchased from Nokia or Nokia-approved resellers. The
Nokia Global Support Services group can provide support only for Nokia products that use
Nokia-approved accessories. For sales or reseller information, contact a Nokia service
provider listed in the “Nokia Contact Information” on page 3.
System Status LEDs
You can monitor the basic operation of the IP390 appliance and NICs by checking their status
LEDs. The system status LEDs are located on the front panel of the appliance, as Figure 4
shows.
Table 4 PMC Network Interface Card Slots
Interface For details, see...
Four-port copper 10/100
Ethernet
“Four-Port 10/100 Mbps Ethernet Network Interface Card” on page 37
Two-port copper Gigabit
Ethernet (10/100/1000 Mbps)
“Two-Port Copper Gigabit Ethernet Network Interface Card” on
page 40
Two-port fiber-optic Gigabit
Ethernet
“Two-Port Fiber-Optic Gigabit Ethernet Network Interface Card” on
page 42
Four-port T1 “Four-Port T1 Network Interface Card” on page 45
