Nokia IP390 - Security Appliance - Figure 10 Ethernet Cable Connector Pin Assignments; Figure 11 Ethernet Crossover-Cable Pin Connections

Four-Port 10/100 Mbps Ethernet Network Interface Card
IP390 Security Platform Installation Guide 39
The following figure shows the pin assignments for the cable. The RJ-45 cable output connector
is numbered from right to left, with the copper tabs facing up and toward you.
Figure 10 Ethernet Cable Connector Pin Assignments
The following figure shows the pin assignments for the RJ-45 cross-over cable.
Figure 11 Ethernet Crossover-Cable Pin Connections
You can also use cables intended for Gigabit Ethernet NIC connections for your Ethernet NIC
connections, as shown in Figure 12.
Pin# Assignment
1TX
2TX
3RX
4
5
6RX
7
8
