IP390 Security Platform Installation Guide 87
A Technical Specifications
Physical Dimensions
Space Requirements
The IP390 appliance is designed for front-screw mounting in a 19-inch rack. Each IP390
appliance requires the following space in a rack:
1.75 inches (4.45 centimeters) of vertical space
18 inches (46 centimeters) behind the front-panel of the rack
6 inches (15 centimeters) behind the IP390 appliance to allow the back exit fan to move air
through the appliances
Caution
Do not place objects over the ventilation holes on the appliance. The appliance might
overheat and become damaged.
Operating Temperature
The operating temperature range for the Nokia IP390 appliance is 0° C to 45° C (32° F to 113°
F).
Dimensions Height: 1.75 in. (4.45 cm)
Width: 17 in. (44 cm)
19 in. (48 cm) rack mountable
Depth: 16.12 in. (40.94 cm)
Weight 17 lbs. (7.7 kg) base system
