Nokia IP560 Security Platform Overview
IP560 Security Platform Installation Guide 25
Note
Nokia products only support NICs purchased from Nokia or Nokia-
approved resellers. The Nokia Global Support Services group can only
provide support for Nokia products that use Nokia-approved accessories.
For sales or reseller information, contact a Nokia service provider listed in
the “Nokia Contact Information” on page 3.
Console Port
Use the built-in console port, shown in Figure 1, to supply information that
makes the appliance available on the network at speeds up to 9600 bps. The
default configuration of the serial ports are: 9600 baud, 8 bits, no parity, and 1
stop. Figure 3 provides pin assignment information for console connections.
If you need to access the devices locally, you must use the console port.
Figure 3 Pin Assignments for Console Connector and Console Cable
Console Port
(DTE)
RJ-45 to RJ-45 Rollover
Cable
RJ-45 to DB-9
Terminal
Adapter Console Device
Signal RJ-45 Pin RJ-45 Pin DB-9 Pin Signal
RTS 1 8 8 CTS
DTR 2 7 6 DSR
TxD 3 6 2 RxD
GND 4 5 5 GND
GND 5 4 5 GND
RxD 6 3 3 TxD
