Signal name Pin number Function
BSI 2 Battery capacity measurement
(fixed resistor inside the battery
pack)
VBAT 1 Positive battery terminal
PWB outline
Figure 118 PWB top side component placement
Figure 119 PWB bottom side component placement
RF description
Frequency band, power and multi-slot class
The requirement leads to the specification in the table below:
RM-512; RM-513; RM-514; RM-515; RM-543
System Module
Page 6 –18 COMPANY CONFIDENTIAL Issue 2
Copyright © 2009 Nokia. All rights reserved.
