NONLINEAR LABS C15 - Page 69

Parameter Reference
Parameter Reference
136 137
Static value of the filter cuto frequency at C3 [in semitones],
applies to both stages of the filter. The osets between their
individual cutos is controlled by “Spread”.
Amount of cuto modulation by Envelope C [in semitones].
Key scaling of the filter cutos.
0.0 %: no influence
100.0 %: full tracking with the keys, origin at C3 = 60 semi-
tones
Amount of filter resonance, creating peaks at the cuto
frequencies.
Amount of resonance modulation by Envelope C.
Key scaling of the filter resonance.
0.0 %: no influence
100.0 %: full tracking with the keys, origin at C3 = 60 semi-
tones
State Variable Filter
Amount of modulation of the cuto frequency of the lowpass
filter by Envelope C [in semitones].
Key scaling of the lowpass cuto frequency.
0.0 %: same cuto for all keys
100.0 %: full tracking with the keys, origin at C3 = 60 semi-
tones
Amount of (phase) modulation of the comb filter pitch (delay
time) by the output signals of Oscillator & Shaper A and B,
with the PM A-B knob determining their mix.
The (phase) modulation signal for the Comb Filter as a
crossfade between the outputs of Oscillator & Shaper A and
Oscillator & Shaper B.
The signal for the State Variable Filter as a crossfade between
the outputs of Oscillator & Shaper A and Oscillator & Shaper
B.
The input signal for the State Variable Filter as mix of the sig-
nals from the A-B mixer and from the Comb Filter. Negative
mix amounts will create dierent Comb Filter (cancellation)
eects.
State Variable Filter
State Variable Filter
