3 Assembly instructions, storage, preparation, installation
B 1000 en-4419 17
3 Assembly instructions, storage, preparation, installation
Please note all safety information (please see chapter 1 "Safety information")and warning information
in the relevant sections.
Pos: 43 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufs tell ung /Tr ans port /Tr ans port des Ge trie bes 01 hea dlin e @ 34\mod_1559812428776_388.docx @ 2539371 @ 2 @ 1
3.1 Transporting the gear unit
Pos: 44 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufs tell ung /Tr ans port /Tr ans port des Ge trie bes 02 [Sta ndar dg etri eb e - Ri ngschr aube] @ 34\mod_1559813589771_388.docx @ 2539562 @ @ 1
Hazard due to falling loads
• The thread of the eye bolt must be fully screwed in.
• Do not pull on the eye bolt at an angle.
• Note the centre of gravity of the gear unit.
Only use the eye bolts attached to the gear unit for transport. If geared motors have an additional eye
bolt attached to the motor, this must also be used.
Pos: 46 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufs tell ung /Tr ans port /Tr ans port des Getrie bes 03 @ 34 \mod_1559812454553_388.docx @ 2539408 @ @ 1
Transport the gear unit with care. Use suitable aids such as cross-beams or similar to facilitate
transportation of the gear unit. Impacts to the free ends of shafts may cause internal damage to the
gear unit.
Pos: 58 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufs tell ung /Lag er ung/ Lag eru ng @ 27\ mod_1551177486988_388.docx @ 2491276 @ 2 @ 1
3.2 Storage
For short-term storage before commissioning, please observe the following:
• Store gear units in the fitting position ((please see chapter 7.1 "Versions and maintenance")) and
secure them against falling,
• Lightly oil bare metal housing surfaces and shafts
• Store in a dry place,
• Temperature in the range from – 5 °C to + 50 °C without large fluctuations,
• Relative humidity less than 60 %,
• No direct exposure to sunlight or UV light,
• No aggressive, corrosive substances (contaminated air, ozone, gases, solvents, acids, alkalis,
salts, radioactivity etc.) in the immediate vicinity,
• No vibration or oscillation
