2.3.2 Electrical connection of power unit
Pos: 13 6 /Anlei tung en/El ektr onik/FU und Star ter/1 . Allg emei nes/Sic herh eits- und Ins tall ations hinwei se un d Warn- Gefahrenhinweise/neu/Warn- un d Gefa hrenhi nweis e/ACHT UNG - EMV-St öru ng der Umgebung [SK 1xxE, SK 2xxE, 5xxE, 5xxP] @ 32\mod_1553501000447_14638.doc x @ 2519287 @ @ 1
NOTICE
EMC interference to the environment
This device produces high-frequency interference which may make additional suppression measures
necessary in domestic environments ( Section
Fehler!
Verweisquelle konnte nicht gefunden
werden. "Fehler! Verweisquelle konnte nicht gefunden werden.").
• Use of shielded motor cables is essential in order to comply with the specified radio interference
suppression level.
Pos: 13 7 /Anlei tung en/El ektr onik/FU und Star ter/2 . Mon tage un d Install atio n/Elek trisc her Ans chlus s/SK 1xxE, SK 2x xE, S K 5xxP, SK xxxE- FDS/ Lei stung st eil/ Elek tri sch er A nsc hlu ss Leis tung st eil_T eil 1 [S K 1xxE , SK 2xx E] @ 7 \mod_1434530744023_14638.docx @ 226340 @ @ 1
Please note the following when connecting the device:
1 Make sure that the AC power supply provides the correct voltage and is suitable for the current
required ( Section 7 "Technical Data").
2 Make sure that suitable branch circuit protection with the specified rated current range are installed
between the voltage source and the device.
3 Power cable connection: to terminals L1-L2/N-L3 and PE (depending on device)
4 Motor connection: to terminals U-V-W
Use a 4-core motor cable if the device is being wall-mounted. In addition to U-V-W, connect PE as
well. In this case, mount the cable shield, if present, on a large area of the metal screw connection
of the cable inlet.
The use of ring cable lugs is recommended for connecting to PE.
Information
Connection cables
Use only copper cables with temperature class 80°C or equivalent for the connection. Higher temperature classes
are permissible.
The maximum connection cross-section can be reduced when using ferrules.
Pos: 13 8 /Anlei tung en/El ektr onik/FU und Star ter/2 . Mon tage un d Install atio n/Elek trisc her Ans chlus s/SK 1xxE, SK 2x xE, S K 5xxP, SK xxxE- FDS/ Leist ungst eil/ Elektri scher Anschl uss Lei stung stei l_Teil 2 [SK 2xx E] @ 7\mod_1434536283290_14638.docx @ 226437 @ @ 1
Device Cable Ø [mm²] AWG Tightening torque
Size rigid flexible [Nm] [lb-in]
1 … 3
0.5 … 6
0.5 … 6
20-10
1.2 … 1.5
10.62 … 13.27
4
0.5 … 16
0.5 … 16
20-6
1.2 … 1.5
10.62 … 13.27
Electromechanical brake
1 … 3
0.2 … 2.5
0.2 … 2.5
24-14
0.5 … 0.6
4.42 … 5.31
4
0.2 … 4
0.2 … 2.5
24-12
0.5 … 0.6
4.42 … 5.31
Table 7: Connection data
