2.4.1.2 Options for ATEX zone 22, category 3D
In order to ensure that the device is ATEX-compliant, its optional modules must also be approved for
potentially explosive areas. Optional modules that are not in the following list may not be used in an
ATEX zone 22 3D. This also includes connectors and switches that may also not be used in such an
environment.
Control and parameterization units are basically not approved for operation in
ATEX - zone 22 3D. They may therefore only be used for commissioning or maintenance purposes
and if it has been ensured that there is no explosive dust atmosphere.
Pos: 175. 14 / Anl eit unge n/ Elek tro nik/F U u nd St arter/ 2. Mo ntag e u nd I nst allati on /AT EX u nd EAC E X (SK 1xxE, SK 200E)/ Optione n für ATEX- Z one 22 3D_02 [SK 2xxE] @ 8\mod_1441016825627_14638.docx @ 238311 @ @ 1
Designation Material number Use permissible
Braking resistors
SK BRI4-1-100-100
275272005
Yes
SK BRI4-1-200-100
275272008
Yes
SK BRI4-1-400-100 275272012 Yes
SK BRI4-2-100-200
275272105
Yes
SK BRI4-2-200-200
275272108
Yes
Bus interfaces
SK CU4-CAO(-C)
275271001 / (275271501)
Yes
SK CU4-DEV(-C) 275271002 / (275271502) Yes
SK CU4-ECT(-C)
275271017 / (275271517)
Yes
SK CU4-EIP(-C)
275271019 / (275271519)
Yes
SK CU4-PBR(-C)
275271000 / (275271500)
Yes
SK CU4-PNT(-C)
275271015 / (275271515)
Yes
SK CU4-POL(-C) 275271018 / (275271518) Yes
IO -extensions
SK CU4-IOE(-C)
275271006 / (275271506)
Yes
SK CU4-IOE2(-C)
275271007 / (275271507)
Yes
SK CU4-REL(-C)
275271011 / (275271511)
Yes
Power supply units
SK CU4-24V-123-B(-C)
275271108 / (275271608)
Yes
SK CU4-24V-140-B(-C)
275271109 / (275271609)
Yes
Potentiometers
SK ATX-POT
275142000
Yes
Miscellaneous
SK CU4-FUSE(-C)
275271122 / (275271622)
Yes
SK CU4-MBR(-C)
275271010 / (275271510)
Yes
Wall mounting kits
SK TIE4-WMK-1-EX
275175053
Yes
SK TIE4-WMK-2-EX
275175054
Yes
Adapter kits
SK TI4-12-Adapter kit_63_71-EX
275175038
Yes
SK TI4-3-Adapter kit_80_112-EX
275175039
Yes
