6 Operating status messages
BU 0240 en-US-4920 79
Pos: 65 5 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Mel dunge n @ 3\mod_1361803071259_14638.docx @ 59852 @ 2 @ 1
6.3 Messages
Pos: 65 6 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Stör mel dung en (Tabel lenü bersc hrift) @ 3\mod_1361803456862_14638.docx @ 59894 @ 5 @ 1
Error messages
Display in the
Simple Box/Control Box
Fault
Text in the Parameter Box
Cause
• Remedy
Group Details in
P700 [-01] /
P701
Pos: 657 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 01 [ SK 1 80E/SK 2xxE/SK 5xxE/SK2xxE-FDS/ SK 500P] @ 2\mod_1347452921592_14638.docx @ 46428 @ @ 1
E001 1.0 Overtemp. inverter
"Inverter overtemperature"
(inverter heat sink)
Temperature monitoring of the inverter
Measuring results lie outside the permissible temperature
range, that is, the error is triggered when falling short of the
permissible lower temperature limit or when exceeding the
permissible upper temperature limit.
• Depending on cause: Reduce or increase ambient
temperature
• Check device fan/cabinet ventilation
• Check the device for dirt
1.1 Overtemp. VFD internal
"Internal VFD overtemperature"
(internal area of the variable
frequency drive)
Pos: 658 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 02 [ SK 1 80E/SK 2xxE/SK 5xxE/SK2xxE-FDS] @ 2\mod_1347453302152_14638.docx @ 46452 @ @ 1
E002 2.0 Overtemp. Motor PTC
"Overtemperature motor PTC"
Motor temperature sensor (PTC thermistor) has triggered
• Reduce motor load
• Increase motor speed
• Use external motor fan
2.1 Overtemp. I²t motor
"Overtemperature I²t motor"
Only if I
2
t motor (P535) is
programmed.
I
2
t motor has triggered (calculated overtemperature of
motor)
• Reduce motor load
• Increase motor speed
2.2 Overtemp. ext. brak. res.
"Overtemperature of external
braking resistor"
Overtemperature via digital
input (P420 […])={13}
Temperature monitor (e.g. braking resistor) has activated
• Digital input is low
• Check connection, temperature sensor
Pos: 65 9 /Allg emein/ Allg emeing ültig e Mod ule/---------Sei tenum bruc h k omp akt --------- @ 13\mod_1476369695906_0.docx @ 2265496 @ @ 1
