NORDAC FLEX (SK 200E ... SK 235E) – Brief instructions for Frequency Inverters
80 BU 0240 en-US-4920
Pos: 660 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 03 [SK 180E/SK 2xxE/SK 5xxE/SK2xxE-FDS] @ 2\mod_1347453304788_14638.docx @ 46477 @ @ 1
E003 3.0 I
2
t overcurrent limit a.c. VFD: I
2
t limit has triggered, e.g. > 1.5 x I
n
for 60 s (also
note P504)
• Continuous overload at VFD output
• Possible encoder fault (resolution, defect,
connection)
3.1 Chopper overtemperature I
2
t Brake chopper: I
2
t limit has activated, 1.5 times values
reached for 60 s (please also pay attention to P554, if
present, and P555, P556, P557)
• Avoid overcurrent in brake resistance
3.2 IGBT overcurrent
125% monitoring
Derating (output reduction)
• 125% overcurrent for 50 ms
• Brake chopper current too high
• For fan drives: enable flying start circuit (P520)
3.3 IGBT overcurrent fast
150% monitoring
Derating (output reduction)
• 150% overcurrent
• Brake chopper current too high
Pos: 661 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 04 [ SK 1 80E/SK 2xxE/SK 5xxE] @ 2\mod_1347453306910_14638.docx @ 46502 @ @ 1
E004 4.0 Overcurrent module Error signal from module (short duration)
• Short circuit or ground fault at VFD output
• Motor cable is too long
• Use external output choke
• Braking resistor faulty or resistance too low

Do not switch off P537!
The occurrence of a fault can significantly shorten the
service life of the VFD or even destroy it.
4.1 Overcurrent measurem
"Overcurrent measurement"
P537 (pulse current switch-off) was reached 3x within 50 ms
(only possible if P112 and P536 are disabled)
• VFD is overloaded
• Drive sluggish, insufficiently sized,
• Ramps (P102/P103) too steep -> Increase ramp time
• Check motor data (P201 … P209)
Pos: 66 2 /Allg emein/ Allg emeing ültig e Mod ule/---------Sei tenum bruc h k omp akt --------- @ 13\mod_1476369695906_0.docx @ 2265496 @ @ 1
Pos: 663 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 05 [ SK 1 80E/SK 2xxE/SK 5xxE/SK2xxE-FDS/ SK 500P] @ 2\mod_1347453309234_14638.docx @ 46527 @ @ 1
E005
5.0
Overvoltage Ud
DC link voltage too high
• Increase deceleration time (P103)
• If necessary, set switch-off mode (P108) with delay
(not with lifting equipment)
• Extend emergency stop time (P426)
• Fluctuating speed (e.g. due to high centrifugal
masses), adjust U/f characteristic curve if
necessary (P211, P212)
Devices with brake chopper:
• Reduce energy return using a braking resistor
• Check the function of the connected braking resistor
(broken cable)
• Resistance value of connected braking resistor too
high
5.1
Mains overvoltage
Line voltage is too high
• See technical data ( Section 7)
Pos: 664 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 06 [ SK 5x xE, SK 2xx E, SK 2xxE- FDS/ SK 500P] @ 2\mod_1361458416246_14638.docx @ 588 08 @ @ 1
E006
6.0
Charging error
DC link voltage is too low
• Line voltage too low
• See technical data ( Section
7)
6.1
Mains low voltage
Line voltage too low
• See technical data ( Section 7)
