4 Commissioning
BU 0240 en-US-4920 57
Pos: 23 6 /Anlei tung en/El ektr onik/FU und Star ter/4 . Inbe trieb nahme/ SK 1xx E, SK 2xx E, -FDS/I nbe triebn ahme G erät/ Konfi gurat ion_0 1 [ SK 2x xE] @ 1 \mod_1343218853713_14638.docx @ 37329 @ 3 @ 1
4.2.2 Configuration
Changes to individual parameters are usually necessary for operation.
However, configuration can be carried out to a limited extent by means of the integrated 8-pole DIP
switch (S1).
Configuration via DIP switch
Avoid mixing DIP switch configuration and (software) parameterization.
Pos: 23 7 /Anlei tu nge n/El ektr onik /FU un d St art er/4 . I nbe tri ebn ahme/ SK 1xx E, S K 2x xE, -FD S/In betrie bnahm e Gerät /Param etri erung [SK 1x 0E, SK 2xx E] (202 1-01-12 11:0 9:58) @ 1\mod_1343219106227_14638.docx @ 37353 @ 4 @ 1
4.2.2.1 Parameterization
The use of a Parameter Box (SK CSX-3H/SK PAR) or the NORDCON- software is required in order to
adapt the parameters.
Parameter group Parameter numbers Functions Comments
limits
Measure stator resistance
P200
Selection of a 4-pole standard
NORD motor from a list
P220, function 2
Complete measurement of a
connected motor
Prerequisite: Motor no more
than 3 power levels less than
the variable frequency drive
Analog and digital inputs
Pos: 23 8 /Anlei tung en/El ektr onik/FU und Star ter/4 . Inbe trieb nahme/ SK 1xx E, SK 2xx E, -FDS/I n betr iebn ahm e G erät /P aram etri er ung _01 ( INF ORM ATI ON-W erk sei nst ellu ng) [SK 2xx E] @ 8\mod_1441360759202_14638.docx @ 240131 @ @ 1
Prior to commissioning, make sure the variable frequency drive is in its factory settings (P523).
If configuration is carried out at parameter level, the DIP- switches (S1) must also be set to the 0 (OFF) position.
