NORDAC FLEX (SK 200E ... SK 235E) – Brief instructions for Frequency Inverters
78 BU 0240 en-US-4920
Diagnostic LEDs
LED Signal
Name Color Description Status Meaning
DOUT 1
yellow
Digital output 1
on
High signal applied
DIN 1
yellow
Digital input 1
on
High signal applied
DIN 2
yellow
Digital input 2
on
High signal applied
DIN 3 yellow Digital input 3 on High signal applied
DIN 4
yellow
Digital input 4
on
High signal applied
TEMP
yellow
Motor PTC
thermistor
on
Motor overtemperature
CHOP yellow Brake chopper on Brake chopper active, brightness → degree of load (only
SK 2x5E)
BRAKE
yellow
Mech. Brake
on
Mech. Brake released
DOUT 2
yellow
Digital output 2
on
High signal present
(only SK 2x0E)
BUS-S
green
System bus
off
No process data communication
Status
Flashing
(4 Hz)
"BUS Warning"
On
Process data communication active
 Receipt of at least 1 telegram/s
 SDO data transfer is not indicated
BUS-E
red
System bus
off
No error
Error
Flashing
(4 Hz)
Monitoring error P120 or P513
 E10.0/E10.9
Flashing
(1 Hz)
Error in an external system bus module
Bus module Timeout on external BUS (E10.2)
 System bus module has module error (E10.3)
on System bus in state "BUS off"
