Control terminal details
Labeling, function
SH:
Function: Safe stop
DOUT:
Digital output
ASI+/-:
Integrated AS interface
24 V SH:
"Safe stop" input
24 V:
24 V DC control voltage
0 V SH:
"Safe stop" reference potential
10 V REF:
10 V DC reference voltage for AIN
AIN +/-
Analog input
AGND:
Reference potential for analog signals
SYS H/L:
System bus
GND:
Reference potential for digital signals
MB+/-:
Control of electromechanical brake
DIN:
Digital input
TF+/-:
PTC thermistor connection of motor
Connections depending on the variable frequency drive type
Detailed information regarding functional safety (safe stop) can be found in supplementary manual
BU0230. - www.nord.com
-
Sizes 1 ... 3
SK 200E SK 210E SK 220E SK 230E Device model SK 205E SK 215E SK 225E SK 235E
SH
ASI
SH+ASI
Labeling
SH
ASI
SH+ASI
Pin
24 V (output)
43
1
44
24 V (input)*
AIN1+
ASI+
14/84
2
44/84
24 V (input)*
ASI+
AIN2+
16
3
40
GND
AGND ASI-
12/85
4
40/85
GND ASI-
DIN1 21 5 21 DIN1
DIN2
22
6
22
DIN2
DIN3
23
7
23
DIN3
DIN4
24 V SH
DIN4
24 V SH
24/89
8
24/89
DIN4
24 V SH
DIN4
24 V SH
GND
0 V SH
GND
0 V SH
40/88
9
40/88
GND
0 V SH
GND
0 V SH
DOUT1
1
10
1
DOUT1
GND
40
11
40
GND
SYS H
77
12
77
SYS H
SYS L
78
13
78
SYS L
10 V REF
11
14
-
---
DOUT2
3
15
79
MB+
GND
40
16
80
MB-
TF+
38
17
38
TF+
TF-
39
18
39
TF-
* when using the AS interface, terminal 44 provides an output voltage (26.5 V DC … 31.6 V DC, max. 60 mA). In this case, no
voltage sources may be connected to this terminal!
