Nord Drivesystems NORDAC FLEX SK 215E Series Brief Instructions

2 Mounting and installation
BU 0240 en-US-4920 45
Overview of required parameter settings:
Parameter Setting value Factory setting Description
P105
maximum frequency
≤ 100 Hz [50]
This value relates to a 4-pole motor.
Basically, the value must only be so large
that a motor speed of 3000 rpm is not
exceeded.
P200
motor list
Select appropriate
motor power
[0]
If a 4-pole NORD motor is used, the pre-set
motor data can be called up.
P201 – P208
Motor data
Data according to
nameplate
[xxx]
If a 4-pole NORD motor is not used, the
motor data on the nameplate must be
entered here.
P218
degree of
modulation
≥ 100% [100]
Determines the maximum possible output
voltage
P220
parameter
identification
1 [0]
Measures the stator resistance of the motor.
When the measurement is complete, the
parameter is automatically reset to 0. The
value that is determined is written to P208
P504
Pulse frequency
4 kHz … 6 kHz [6]
For pulse frequencies above 6 kHz a
reduction of the maximum torque is
necessary.
P533
I
2
t motor factor
< 100% [100]
A torque reduction can be taken into account
with values less than 100 in I²t monitoring.
P535
I²t motor
According to motor
and ventilation
[0]
The I²t monitoring of the motor must be
switched on. The set values depend on the
type of ventilation and the motor used, see
B1091-1
