PICO Toµch Controller
13www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Operating Features
Front Panel
Back Panel
Touchscreen
Cycle LED
(clear or blue)
Power LED
(red or green)
Nordson EFD
use only
USB port (for PC
communication)
I/O 1 port
Power switch
VALVE communication
connection (5-pin)
VALVE power
connection (3-pin)
Fuse
DC power input
Ground terminal
VALVE screen
icon
HEATERS
screen icon
RAMP screen
icon
SETTINGS
screen icon
I/O 2 port (includes
RS-232 terminals)
