Nordson EFD PICO Touch User Manual

PICO Toµch Controller
12 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Specifications
NOTE: Specications and technical details are subject to engineering change without prior notication.
Item Specification
Cabinet size 14.2
W x 13.3H x 16.8D cm ( 28 Hp x 3U)
5.6W x 5.25H x 6.6D"
Weight 2.6 kg (5.5 lb)
Material Aluminum / steel
Input AC (to power supply) 100–240 VAC +/-10%, 50–60 Hz, 2 Amp
Output DC (from power supply) 24 VDC, 6.25 Amp
Internal voltage 150 VDC, 24 VDC, 5 VDC, and 3.3 VDC
Heater output voltage 24 VDC, 30 W maximum
Feedback circuit 0–24 VDC
Initiate circuit 15–24 VDC (must be a clean, bounce-free signal)
Heater outputs Setpoint range: 0–100° C; 0.1° C increments
Temperature input type at valve: RTD
Indication accuracy: ±1° C
Sample rate: 60 per second
Control method: PID
NOTE: No valve cooling is possible.
Cycle rate Valve-dependent
Time range 100 µs to 9.9999 s (depending on the open prole time)
Ambient operating conditions Temperature: 5–45° C (41–133° F)
Humidity: 85% relative humidity at 30° C (86° F), non-condensing
Height above sea level: 2000 m (6,562 ft) maximum
Indoor use only
Product classication Installation category II
Pollution degree 2
Approvals CE, RoHS, WEEE, and China ROHS compliant
RoHS标准相关声明 (China RoHS Hazardous Material Declaration)
产品名称
Part Name
有害物质及元素
Toxic or Hazardous Substances and Elements
铅 
Lead
(Pb)
汞 
Mercury
(Hg)
镉 
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr6)
多溴联苯
Polybrominated
Biphenyls
(PBB)
多溴联苯醚
Polybrominated
Diphenyl Ethers
(PBDE)
外部接口
External Electrical
Connectors
X 0 0 0 0 0
O:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准低于SJ/T11363-2006限定要求。
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is below
the limit requirement in SJ/T11363-2006.
X: 表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准高于SJ/T11363-2006限定要求.
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is above
the limit requirement in SJ/T11363-2006.
WEEE Directive
This equipment is regulated by the European Union under WEEE Directive (2012/19/EU). Refer to www.
nordsonefd.com/WEEE for information about how to properly dispose of this equipment.

Nordson EFD PICO Touch Specifications

General

Brand	Nordson EFD
Model	PICO Touch
Category	Controller
Language	English
