PICO Toµch Controller
18 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
HOME Screen
All secondary and tertiary screens are accessed through the HOME screen.
Icon Description
VALVE
Opens the VALVE screen. Refer to "VALVE Screen" on page 19.
HEATERS
Opens the HEATERS screen. Refer to "HEATERS Screen" on page 21.
RAMP
Opens the WAVE PROFILE screen. The WAVE PROFILE screen provides access to the RAMP
and RAMP GRAPH screens. Refer to "WAVE PROFILE Screen" on page 22.
SETTINGS
Opens the SETTINGS screen. The SETTINGS screen provides access to all system-related
setup screens. Refer to "SETTINGS Screen" on page 23.
